Pattern router bits with insert knives Z2 with bearing guide

Cod: FR.404

Milling machine with straight cutting edges and an interchangeable knife fastened with Torx screw. Appropriate for all the applications that don't require a lot of time nor a big economic investment. Use it on portable milling machines, point-to-point machines and CNC pantographs.
Open Orders – Shipping from 12,00 € – FREE over 200,00 €.

Special high resistance steel, used by company same as Ferrari® e Porche®.

Tungsten carbide knife 3 times more STRONG and DURING compared to economical alternatives thanks to our technological treatments based on a SPECIAL and SECRET combination of heat & pressure during the sintering

● 2 x Knife cutting edge in Tungsten Carbide (Z2)

Bearing under the cutting edge

BITTOP (?) attached , for optimize and protect your tools

Free ship in Italy Over 80€

Legend:

  • D= Cutting diameter (mm)
  • I= Cutting height (mm)
  • L= Total length (mm)
  • S= Diameter of attack (mm)
  • R= Size Range (mm)
  • K= Body thickness (mm)
  • D3= Internal diameter (mm)
  • A= Steepness (mm)
From: €48.25

* Required Fields

Image Diameter (D) Cutting length (I) Total length (L) № of teeth (Z) D attach (S) A H Cod. Price Stock Qty
19 12 56 2 6 - - 404.190S.6D €48.25
19 12 56 2 6.35 - - 404.190S.635D €48.25
19 12 56 2 8 - - 404.190S.8D €48.25
19 30 74 2 6 - - 404.190.6D €52.81
19 30 74 2 8 - - 404.190.8D €52.81
19 30 87 2 12.7 - - 404.190L.127D €52.81
19 50 87 2 12 - - 404.190XL.12D €61.28
19 50 112 2 12.7 - - 404.190XL.127D €61.47

Specs



● Finishes

● Millings

● Sloping cuts

● Grooves

● Shape



● PANELS (LAMINATES, MDF) AND HARD WOOD



● Never use consumed or damaged router bits

● Work with an adequate speed of progress, never force the tool

● Be particularly careful when enter the wood with router bits that have a small diameter

● Clean the tool with the BITTOP

● In order to obtain better results with small diameters, carry out the cut several times
